MT7206ACH1P4 Turbo Pump bearing LNG Pump

MT7206ACH1P4 Turbo Pump bearing LNG Pump
  • MT7206ACH1P4 Turbo Pump bearing LNG Pump
  • MT7206ACH1P4 Turbo Pump bearing LNG Pump
  • MT7206ACH1P4 Turbo Pump bearing LNG Pump
  • MT7206ACH1P4 Turbo Pump bearing LNG Pump
  • MT7206ACH1P4 Turbo Pump bearing LNG Pump
  • Name:MT7206ACH1P4
  • d:30MM
  • D:62MM
  • B:16MM
  • Cage Material:PTFE cage
  • Weight:0.19KG
  • Original:Luoyang
Inquiry Now
NameTurbo Pump bearing
BrandMONTON
ModelMT7206ACH1P4
Contact angle15°
Bore diameter30mm
Outside diameter62mm
B(width)16mm
Ring MaterialSpecail Bearing steel
Cage MaterialPTFE cage
SealedOpen
RowSingle row
Weight0.19KG
Quality standardISO9001: 2000/SGS
Packagesingle box
OriginalLuoyang
ServiceOEM
Delivery dateStock
ApplicationTurbo Pump
cryogenic turbo pump
LOX Turbo Pump
LNG Pump



The bearings of liquid oxygen turbopump are the core components of the fuel delivery system of rocket engines and need to maintain stable operation under extremely low temperatures (liquid oxygen temperature reaching -183℃) and ultra-high-speed rotation (usually exceeding 20,000 RPM) conditions. In a liquid oxygen environment, traditional lubricants are prone to failure. Self-lubricating technologies, such as cage materials based on polytetrafluoroethylene (PTFE) or polyetheretherketone (PEEK), should be adopted to prevent low-temperature embrittlement. Bearing materials need to take into account both low-temperature toughness and wear resistance. Commonly used ceramic bearings are silicon nitride (Si3N4) or zirconia (ZrO2), or special alloy steel combined with low-temperature heat treatment processes.
