Bearing type :YRTM325
Dimensions(mm)
d :325
D :450
H :60
H1 :40
H2 :20
C :20
D1 :412.6
D2 :415
dn :342
dm :430
F :342
L :430
Inner ring(mm)
d1 :9.3
d2 :15
a :8.2
qty :34
Outer ring(mm)
d3 :9.3
qty :33
number of connecting bolts :2
Axial and radial runout(μm)
Standard :6
Strictly :3
Extraction thread hole
G :M12
qty :3
Number of pitchesX angle of pitches
Qty×t :36×10°
Screw tightening torque(Nm)
MA2) :34
Basic load rating(KN)
axial
Ca :275
Coa :1930
radial
Co :120
Cor :345
rigidity(kNm/mrad)
CkL :630
CkL1 :105
Bearing frictional torque(Nm) :40
Weight(kg) :25
