7400B Series Angular Contact Ball Bearings

PDF

select	Inquiry	Bearing No.	Boundary dimensions（mm）			Basic load ratings(kN)		Limiting speed(rpm )		Mass
select	Inquiry	Bearing No.	d	D	B	Dynamic(Cr)	Static(Cor)	Grease	Oil	Kg
		7406B	30	90	23	51.4	30.1	6000	8000	0.9
		7407B	35	100	25	60.2	37.9	5000	7500	1.1
		7408B	40	110	27	70.1	49.1	5000	6500	1.35
		7409B	45	120	29	80.7	44.1	4500	6000	1.75
		7410B	50	130	31	105.3	71.2	4000	5500	2.1
		7411B	55	140	33	110	76.3	3800	5200	2.55
		7412B	60	150	35	119.3	86.1	3500	4700	3.2
		7413B	65	160	37	128.7	96.4	3200	4500	4
		7414B	70	180	42	138.7	109.6	3000	4200	5.55
		7415B	75	190	45	148.4	120.4	2800	4000	6.8
		7416B	80	200	48	158.4	132.4	2600	3700	8.18
		7417B	85	210	52	168.6	145	2400	3400	9.3
		7418B	90	225	54	179.1	159.2	2300	3200	10.8
