51300 Series

PDF

select	Inquiry	Designation	Principal Dimensions(mm)			Basic Load Ratings(KN)		Limited Speed(rpm)		Weight
select	Inquiry	Designation	d	D	T	Dynamic(Cr)	Static(Cor)	Grease	Oil	(kg)
		51305	25	52	18	35.5	61.5	3000	4300	0.17
		51306	30	60	21	42.8	78.5	2400	3600	0.26
		51307	35	68	24	55.2	105	2000	3200	0.37
		51308	40	78	26	69.2	135	1900	3000	0.53
		51309	45	85	28	75.8	150	1700	2600	0.66
		51310	50	95	31	96.5	202	1600	2400	0.92
		51311	55	105	35	115	242	1500	2200	1.28
		51312	60	110	35	118	262	1400	2000	1.37
		51313	65	115	36	115	262	1300	1900	1.48
		51314	70	125	40	148	340	1200	1800	1.98
		51315	75	135	44	162	380	1100	1700	2.58
		51316	80	140	44	160	380	1000	1600	2.69
		51317	85	150	49	208	495	950	1500	3.47
		51318	90	155	50	205	495	900	1400	3.69
		51320	100	170	55	235	595	800	1200	4.86
