1200 Series

PDF

select	Inquiry	Bearing Designation	Dimension（mm）				Basic load ratings (kN)		Speed ratings(rpm)		Weight
select	Inquiry	Bearing Designation	d	D	B	rs min	Cr	Cor	Grease	Oil	(Kg)
		1200	10	30	9	0.6	5.5	1.19	21000	24000	0.033
		1201	12	32	10	0.6	5.6	1.27	18000	22000	0.04
		1202	15	35	11	0.6	7.45	1.75	16000	19000	0.049
		1203	17	40	12	0.6	7.9	2.01	14000	17000	0.072
		1204	20	47	14	1	9.9	2.61	13000	15000	0.116
		1204K	20	47	14	1	9.9	2.61	13000	15000	0.114
		1205	25	52	15	1	12.1	3.3	11000	13000	0.138
		1205K	25	52	15	1	12.1	3.3	11000	13000	0.135
		1206	30	62	16	1	15.6	4.65	9200	11000	0.217
		1206K	30	62	16	1	15.6	4.65	9200	11000	0.213
		1207	35	72	17	1.1	15.8	5.1	8000	9400	0.317
		1207K	35	72	17	1.1	15.8	5.1	8000	9400	0.312
		1208	40	80	18	1.1	19.3	6.55	7100	8400	0.414
		1208K	40	80	18	1.1	19.3	6.55	7100	8400	0.407
		1209	45	85	19	1.1	21.9	7.35	6400	7500	0.457
		1209K	45	85	19	1.1	21.9	7.35	6400	7500	0.448
		1210	50	90	20	1.1	22.7	8.1	5800	6800	0.515
		1210K	50	90	20	1.1	22.7	8.1	5800	6800	0.504
		1211	55	100	21	1.5	26.8	10	5300	6200	0.692
		1211K	55	100	21	1.5	26.8	10	5300	6200	0.679
		1212	60	110	22	1.5	30	11.5	4900	5800	0.879
		1212K	60	110	22	1.5	30	11.5	4900	5800	0.864
		1213	65	120	23	1.5	31	12.5	4500	5300	1.13
		1213K	65	120	23	1.5	31	12.5	4500	5300	1.11
		1214	70	125	24	1.5	34.5	13.8	4200	4900	1.24
		1215	75	130	25	1.5	39	15.7	3900	4600	1.33
		1215K	75	130	25	1.5	39	15.7	3900	4600	1.31
		1216	80	140	26	2	40	17	3700	4300	1.65
		1216K	80	140	26	2	40	17	3700	4300	1.62
		1217	85	150	28	2	49	20.8	3500	4100	2.06
